Psa Nitrogen Generator Machine with Skid-Mounted Design
PSA nitrogen generators
The technology of air-to-nitrogen generation with the use of adsorption processes in PSA nitrogen generators is well studied and widely applied at industrial facilities for the recovery of high-purity nitrogen. This is then used in many industries from food packaging to supporting laboratory instrumentation such as Liquid Chromatography Mass Spectrometry (LC-MS) and Gas Chromatography (GC).
PSA nitrogen generators for these scientific applications are designed to produce high purity nitrogen by regulating gas adsorption and adsorbent regeneration by changing pressures in two adsorber-adsorbent containing vessels. This process requires a constant temperature, close to ambient.
The swing adsorption process in each of the two adsorbers consists of two stages running at intervals of a few minutes. At the adsorption stage oxygen, moisture and carbon dioxide molecules diffuse into the pore structure of the adsorbent whilst the nitrogen molecules are allowed to travel through the adsorber–adsorbent-containing vessel to be delivered as high purity nitrogen to the application.
Product Parameters
| Nitrogen production (Nm³/h) | Effective air consumption (Nm³/min) | Inlet pipe size (DNmm) | Outlet pipe diameter (DNmm) | Host L×W(mm) |
| 5 | 0.7 | 25 | 15 | 1150×600 |
| 10 | 1.4 | 25 | 15 | 1250×880 |
| 20 | 2.8 | 40 | 15 | 1750×1000 |
| 30 | 4.2 | 40 | 25 | 2150×1100 |
| 40 | 5.6 | 50 | 25 | 2250×1140 |
| 50 | 7.0 | 50 | 25 | 2500×1150 |
| 60 | 8.4 | 50 | 25 | 2750×1450 |
| 80 | 11.2 | 65 | 32 | 2750×1450 |
| 100 | 14.0 | 65 | 32 | 2850×1550 |
| 200 | 28.0 | 65 | 32 | 3250×1820 |
| 300 | 42.0 | 80 | 40 | 3500×2150 |
Specification
PSA (Pressure swing adsorption) Nitrogen Generator
Purity: 95%--99.9995%
OEM manufacurer, rated flow: 3--6000Nm3/h, customized
Pressure: 0.8Mpa & adjustable
Dew point: ≤-45oC
Resonable price with high quality, ISO certificate,TUV certified.
Key Configurations
* Provide maximum business value
* Molecular sieve filling and compacting, adopt the professional way to complete in a professional context, higher density, higher efficiency
* Design optimization, process and structure of the system, to play the greatest potential, higher reliability
* Special valve by one million times, frequent switching fault free,and stable operation of security system
* Nitrogen can automatically record, easy to locate any work time ,work state
* System design more reasonable, more secure, more reliable.
* Automatic operation, the system, the whole process can be achieved unattended.
Applicable industry
Nitrogen generators are essential equipment used in various industries such as petroleum, glass manufacturing, food packaging, and laser cutting. These generators are designed to produce high-purity nitrogen gas on-site, eliminating the need for traditional nitrogen gas cylinders.
In the petroleum industry, nitrogen generators are used for blanketing storage tanks, purging pipelines, and preventing explosions in hazardous environments. In glass manufacturing, nitrogen is used to create an inert atmosphere during the production process, resulting in higher quality glass products.
Food packaging companies rely on nitrogen generators to extend the shelf life of perishable goods by displacing oxygen and inhibiting the growth of bacteria and mold. Additionally, nitrogen gas is widely used in laser cutting applications to prevent oxidation and improve cutting quality.
Overall, nitrogen generators offer a cost-effective and reliable solution for industries requiring a continuous supply of high-purity nitrogen gas. With their advanced technology and efficient operation, these generators play a crucial role in enhancing productivity and ensuring product quality in a wide range of industrial applications.
| Packaging |
| Size | 123 (L) * 456 (W) * 789 (D) |
| Weight | 1.2 T |
| Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. |
In addition to psa nitrogen generator, we also produce VPSA Oxygen Generators,PSA Oxygen Generators, storage tanks, heat exchangers and other products. If you are interested in psa nitrogen Systems or other products, please feel free to send an email to info@gneeheatex.com. We will be very happy to serve you.
Product Tags:
|
|
PSA Nitrogen Generator with 220v/380v/50-60hz Voltage 3-20Nm3/h Flow Rate and OEM Offered Images
|
