China Small Psa Nitrogen Generator N2 Gas Making Machine Plant for Food Packaging and Industry
Product Description
The Pressure Swing Adsorption Nitrogen Generator (referred to as PSA Nitrogen Generator for short) is a device that separates high-purity nitrogen from compressed air using the principle of physical adsorption. It is one of the most widely used, economical and efficient on-site nitrogen generation technologies in industry today.
Product Parameters
| Output(Nm³/h) | Effective gas consumption
(Nm³/min) | Air purification system | Import and export caliber(mm) |
| 10 | 0.45 | CJ-1 | DN74 | DN15 |
| 20 | 0.92 | CJ-1 | DN25 | DN25 |
| 30 | 1.3 | CJ-2 | DN25 | DN25 |
| 40 | 1.8 | CJ-2 | DN32 | DN25 |
| 60 | 2.2 | CJ-3 | DN32 | DN25 |
| 80 | 3.5 | CJ-6 | DN40 | DN32 |
| 100 | 4.14 | CJ-6 | DN40 | DN32 |
| 120 | 4.89 | CJ-6 | DN50 | DN40 |
| 150 | 6.11 | CJ-10 | DN50 | DN40 |
| 200 | 8.18 | CJ-10 | DN50 | DN40 |
| 300 | 12.22 | CJ-20 | DN65 | DN50 |
| 400 | 16.45 | CJ-20 | DN65 | DN50 |
| 600 | 24.91 | CJ-30 | DN80 | DN50 |
| 800 | 32.90 | CJ-40 | DN100 | DN65 |
| 1000 | 42.30 | CJ-50 | DN125 | DN65 |
| 1200 | 48.88 | CJ-50 | DN125 | DN65 |
| 1500 | 61.10 | CJ-70 | DN125 | DN100 |
| 2000 | 81.78 | CJ-90 | DN150 | DN100 |
| 2500 | 101.52 | CJ-110 | DN200 | DN125 |
Products Advantages
1. Equipped with automatic inflation system, with memory function;
2. Automatic inflation system, easy to operate, display tire pressure;
3. Digital display, unit conversion is simple, key operation;
4. Nitrogen purity up to 96%, increase tire life;
5. Automatic vacuum system
6. Activated carbon molecular sieve has stable quality and long service life
7.AB twin tower CMS-260 activated carbon molecular sieve
8. Suitable for cars and motorcycles
9.20L gas storage tank
10. Equipped with 10 meters inflation tube
11. Equipped with oil and water separation filter
- The main parts are imported
- The compatible medium: compressed air is filtered twice
(1): Primary filtration: three-stage precision filter of high-quality materials
(2): secondary filtration, high quality, large capacity activated carbon filter device.
Brief introduction of process principle:
Pressure swing adsorption nitrogen production is based on clean, dry compressed air as raw material, and uses a high-efficiency and highly selective solid adsorbent (carbon molecular sieve) to selectively adsorb nitrogen and oxygen to reduce the nitrogen and oxygen in the air. separate from. Carbon molecular sieves are non-polar molecules and preferentially adsorb oxygen. The separation effect of carbon molecular sieve on oxygen and nitrogen is mainly based on the different diffusion rates of these two gases on the surface of carbon molecular sieve. Gas with a smaller diameter (oxygen) diffuses faster, and more enters the solid phase of the molecular sieve. Gas with a larger diameter ( Nitrogen) diffuses slowly and less enters the solid phase of molecular sieve. In this way, nitrogen-rich components can be obtained in the gas phase. After a period of time, the adsorption of oxygen by molecular sieve reaches equilibrium. According to the different characteristics of carbon molecular sieve for adsorbing gas under different pressures, the pressure is reduced to release carbon molecular sieve from adsorbing oxygen. This process is called regeneration. The pressure swing adsorption method usually uses two towers in parallel, alternately performing pressure adsorption and decompression regeneration, so as to obtain a continuous nitrogen stream.
| Packaging |
| Size | 123 (L) * 456 (W) * 789 (D) |
| Weight | 1.2 T |
| Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. |
In addition to psa nitrogen generator, we also produce VPSA Oxygen Generators,PSA Oxygen Generators, storage tanks, heat exchangers and other products. If you are interested in psa nitrogen Systems or other products, please feel free to send an email to info@gneeheatex.com. We will be very happy to serve you.
