30 m³ Best Vertical Cryogenic Liquid Storage Tank for Filling Station
Product Description
The cryogenic liquid storage tank is double-walled; the inner material is S3048 stainless steel, and the outer material is Q245R carbon steel. It concludes vertical and horizontal structure, adopt the use of vacuum powder adiabatic, with the advantage of compact structure , low issuance date, small footprint, centralized control, safe,reliable,easy operation and maintenance.
Product Parameters
| Working Medium | Volume (M³) | Weight | Size (mm) | Working Pressure |
| LO2/LAR/LN2 | 5 | 3412 | Φ2000*5130 | 0.8MPa |
| 10 | 5378 | Φ2100*7170 |
| 15 | 6415 | Φ2500*6912 |
| 20 | 8673 | Φ3000*6100 |
| 30 | 12899 | Φ2900*8870 |
| 50 | 18960 | Φ3100*12058 |
| 100 | 34480 | Φ3600*15947 |
| 150 | 53500 | Φ3600*23000 |
| 200 | 65500 | Φ3924*26000 |
| LO2/LAR/LN2 | 5 | 3945 | Φ2000*5130 | 1.6MPa |
| 10 | 6787 | Φ2000*7895 |
| 15 | 8628 | Φ2400*7552 |
| 20 | 10744 | Φ2400*9371 |
| 25 | 13500 | Φ2700*8980 |
| 30 | 14640 | Φ2700*10310 |
| 40 | 19884 | Φ3100*9985 |
| 50 | 23370 | Φ3100*12058 |
| 100 | 44050 | Φ3400*17930 |
Product packaging
1.40otc &40ft container
2.No packing or Seaworthy packing
3.Customer's Request
Quality Promise
1.Product technology level:
They are designed, manufactured, inspected, and accepted in accordance with advanced European and American national standards and specifications, and meet the requirements of Chinese national standards and specifications.
2.Overall product quality assurance:
Ensure that the product design, manufacturing, inspection, and acceptance processes (design → procurement → component manufacturing and welding → assembly → inspection and testing → non-destructive testing → final assembly and packaging before delivery) are effectively implemented in strict accordance with the requirements of the ISO9001 quality management system Control and form records, the buyer can select control points to the site for inspection and confirmation as required, and the factory will provide the necessary working conditions.
GNEE was founded in 2008 and is located at No.4-1114, Beichen Building, Beicang Town, Beichen District, Tianjin, China. It is an entity enterprise engaging in high-end industrial equipment manufacturing, focusing on the R&D, manufacturing and related technical services of industrial heat exchange equipment and pressure vessels.
Since its establishment, the company has adhered to the philosophy of "achieving customers, making employees happy; embracing changes, valuing actions; there is no best, only better". With the goal of providing one-stop services to make choices easier, it has been deeply engaged in industrial heat exchange equipment for many years and has become an excellent and irreplaceable presence in the industry.
