Q245R Cryogenic Pressure Vessel 1.6Mpa Working Pressure

Name: Q245R Cryogenic Pressure Vessel 16Mpa Working Pressure
Brand: Gnee
Price: 1 USD

Brand Name : Gnee

Certification : ISO

Place of Origin : henan

MOQ : 1

Price : bargain

Payment Terms : T/T,L/C,Paypal,Alipay,West Union and so on

Supply Ability : 25 every month

Delivery Time : 15days

Packaging Details : wooden box

Outer cylinder material : Q245R

Dimension(L*W*H) : 2200 mm diameter, 12000 mm length

Application : Chemcial Storage

Video outgoing-inspection : Provided

Capacity : 2-250 m3, 2-250m3

inner cylinder material : S30408

Contact Now

Cryogenic Vessel Storage Tanks Cryogenic Storage Tank

Description

Offers a complete line of large cryogenic storage tanks and solutions that deliver proven reliability, reduce maintenance and minimize the cost of ownership for all types of liquefied gases.

Parameter

Model	CFL /1.6
Effective Capacity	5000L
Working Pressure	1.6Mpa
Design Temp	-196°C (inner tank)
Inner Material	S30408
Outer Material	Q245R
Insulation Type	High Vacuum powder insulation
Fillling Rate	95%
Loading medium	LO2,LN2,LAr
Design Standard	a.GB150 b.GB/T 18442< Cryogenic >Insulation Pressure Vessels> c.TSGR0004

Feature

1.The installation site of the liquid oxygen storage tank must have good ventilation conditions or be equipped with ventilation and ventilation devices, and can safely discharge liquid and gas. 2.The installation site of the liquid oxygen storage tank must be provided with a safety exit, and safety signs should be set up around it. The requirements of the safety signs should comply with the relevant provisions of GB2894. 3.The installation foundation of the liquid oxygen storage tank must be solid and firm. It should be fire-resistant and heat-resistant. The foundation for installing liquid oxygen equipment must be free of grease and other combustibles, and asphalt ground is strictly prohibited
